Galvanized Side Mount Spare Tire Carrier
$49.99 $45.75
Brand Com-Fab
General
Galvanized Side Mount Spare Tire Carrier
- This item is optional for all of our Galvanized Trailer models.
- It can accommodate wheels from 10" to 16.5" with a spare tire.
- It fits all 4 and 5 lug wheels with 4" and 4.5" diameter hole patterns.
- The galvanized finish provides long lasting protection.
- The item can mount to trailer frames up to 3" wide and 4" high.
*Used on Galvanized Trailer Models Only
TIEDOWN MODEL: #86098
MODEL: CFSTB-SIDE(G)
Installation Instructions
1. Using the spare tire carrier and spare tire as a guide, determine a suitable mounting location on trailer frame.
2. Slide U-bolt around the frame and through the holes in tire carrier.
3. Mount with flat washers, lock washers and nuts provided.
4. Using the spare tire to determine the correct holes to use, place the carriage bolts provided for mounting the spare tire in the holes of the rectangular plate. Bolt heads should be on the back side of the tire carrier. Secure bolts with “star” washers.
5. The mounting plate will accommodate several sizes of frames by using the various hole patterns.
6. Check position of the tire mount for proper clearance with the spare tire before tightening bolts.
7. Mount spare tire with 1/2" bolt, washers and hex nuts provided.
Optional for
ALL GALVANIZED TRAILER MODELS
Galvanized Side Mount Spare Tire Carrier
- This item is optional for all of our Galvanized Trailer models.
- It can accommodate wheels from 10" to 16.5" with a spare tire.
- It fits all 4 and 5 lug wheels with 4" and 4.5" diameter hole patterns.
- The galvanized finish provides long lasting protection.
- The item can mount to trailer frames up to 3" wide and 4" high.
*Used on Galvanized Trailer Models Only
TIEDOWN MODEL: #86098
MODEL: CFSTB-SIDE(G)
1. Using the spare tire carrier and spare tire as a guide, determine a suitable mounting location on trailer frame.
2. Slide U-bolt around the frame and through the holes in tire carrier.
3. Mount with flat washers, lock washers and nuts provided.
4. Using the spare tire to determine the correct holes to use, place the carriage bolts provided for mounting the spare tire in the holes of the rectangular plate. Bolt heads should be on the back side of the tire carrier. Secure bolts with “star” washers.
5. The mounting plate will accommodate several sizes of frames by using the various hole patterns.
6. Check position of the tire mount for proper clearance with the spare tire before tightening bolts.
7. Mount spare tire with 1/2" bolt, washers and hex nuts provided.
ALL GALVANIZED TRAILER MODELS
TecNiq-T86 7 Function 6" LED Tail Light (Passenger Side)
$34.99 $24.00
Brand Com-Fab
General
TecNiq-T86 7 Function 6" Box LED Passenger Side Tail Light w/ Pigtail
- These are optional for all Trailer Models.
- Multi-Function 6" Box Tail Light
- Urethane Potting w/ Guaranteed Circuit Board Protection
- Dust and water proof with hermetic seal
- Durable impact resistant lens
- Meets all FMVSS 108 requirements for narrow and wide vehicles
- Reliable performance over 100,000 hours
- Fits standard mounting as a direct replacement
- Functions include: Stop, Turn, Tail, Clearance, Side marker, Side Reflector,
Rear Reflector, and License Plate Light (Left)
Includes two 7/16" bolts w/ nuts for mounting.
MODEL: CFLIGHTREAR(R)-LED(TEC)
Used on
ALL COM-FAB TRAILER MODELS
TecNiq-T86 7 Function 6" Box LED Passenger Side Tail Light w/ Pigtail
- These are optional for all Trailer Models.
- Multi-Function 6" Box Tail Light
- Urethane Potting w/ Guaranteed Circuit Board Protection
- Dust and water proof with hermetic seal
- Durable impact resistant lens
- Meets all FMVSS 108 requirements for narrow and wide vehicles
- Reliable performance over 100,000 hours
- Fits standard mounting as a direct replacement
- Functions include: Stop, Turn, Tail, Clearance, Side marker, Side Reflector,
Rear Reflector, and License Plate Light (Left)
Includes two 7/16" bolts w/ nuts for mounting.
MODEL: CFLIGHTREAR(R)-LED(TEC)
ALL COM-FAB TRAILER MODELS
TecNiq-T86 8 Function 6" LED Tail Light (Driver Side)
$34.99 $25.75
Brand Com-Fab
General
TecNiq-T86 8 Function 8" Box Driver Side Tail Light w/ Pig Tail.
-
Multi-Function 6" box tail light
-
Urethane Potting w/ Guaranteed Circuit Board Protection
-
Dust and water proof with hermetic seal
-
Durable impact resistant lens
-
Meets all FMVSS 108 requirements for narrow and wide vehicles
-
Reliable performance over 100,000 hours
-
Fits standard mounting as a direct replacement
-
Functions include: Stop, Turn, Tail, Clearance, Side marker, Side Reflector,
Rear Reflector, and License Plate Light (Left)
Includes two 7/16" bolts w/ nuts for mounting.
MODEL: CFLIGHTREAR(L)-LED(TEC)
Used on
ALL COM-FAB TRAILER MODELS
TecNiq-T86 8 Function 8" Box Driver Side Tail Light w/ Pig Tail.
-
Multi-Function 6" box tail light
-
Urethane Potting w/ Guaranteed Circuit Board Protection
-
Dust and water proof with hermetic seal
-
Durable impact resistant lens
-
Meets all FMVSS 108 requirements for narrow and wide vehicles
-
Reliable performance over 100,000 hours
-
Fits standard mounting as a direct replacement
-
Functions include: Stop, Turn, Tail, Clearance, Side marker, Side Reflector,
Rear Reflector, and License Plate Light (Left)
Includes two 7/16" bolts w/ nuts for mounting.
MODEL: CFLIGHTREAR(L)-LED(TEC)
ALL COM-FAB TRAILER MODELS
1200 lb Side Crank Swivel Jack
$49.99
Brand Com-Fab
General
1200 lb Side Crank Swivel Jack
This item fits 3″ x 5“ tongues. It comes with a 1200 lb Side Crank Swivel Jack Mounting Kit.
MAXIMUM CAPACITY: 1200LB
PACIDIC RIM MODEL: MJ-1200B
MODEL: CFJACKSIDE
Used on
JBT-900
JBT-1400
JBT-1600
JBT-1600 ‘RIVER HAWK’
PT-1400 'MiniToon'
PT-1618
PT-1820
PT-2022
1200 lb Side Crank Swivel Jack
This item fits 3″ x 5“ tongues. It comes with a 1200 lb Side Crank Swivel Jack Mounting Kit.
MAXIMUM CAPACITY: 1200LB
PACIDIC RIM MODEL: MJ-1200B
MODEL: CFJACKSIDE
JBT-900
JBT-1400
JBT-1600
JBT-1600 ‘RIVER HAWK’
PT-1400 'MiniToon'
PT-1618
PT-1820
PT-2022
