Parts Kits

General

1000/1100G - Bunk Mounting Kit

These are all of the requisite materials needed to mount a 2″ x 4″ x 6′ Carpeted Black Marine Bunk Board onto PWT-1000G trailer models, as well as a 2″ x 4″ x 7′ Black Marine Carpeted Bunk Board onto a PWT-1100G trailer model.

4 – 5/16" x 1-1/2″ Galvanized Hex Head Lag Screw

MODEL: CFBNKKIT-1000/1100G

Used on

General

1000/1100B - Bunk Mounting Kit

These are all of the requisite materials needed to mount a 2″ x 4″ x 6′ Carpeted Black Marine Bunk Board onto PWT-1000B trailer models, as well as a 2″ x 4″ x 7′ Black Marine Carpeted Bunk Board onto a PWT-1100B trailer model.

4 – 5/16" x 1-1/2″ Galvanized Hex Head Lag Screw

MODEL: CFBNKKIT-1000B

Used on

General

2213/4G - Bunk Mounting Kit

These are all of the requisite materials needed to mount a 2″ x 4″ x 6′ Black Marine Carpeted Bunk Board onto a 2213G trailer model. The kit can also be used to mount a 2″ x 4″ x 7′ Black Marine Carpeted Bunk Board onto a 2214G trailer model.

Materials Include:

4 – 5/16" x 1-1/2″ Galvanized Hex Head Lag Screw

MODEL: CFBNKKIT-2213G

Used on

General

2213/4G - Fender Mounting Kit

This kit contains all of the requisite materials needed to mount a Galvanized Fender 13" Tire onto 2213G, 2214G, and Pre-2019 Single Axle Pontoon Boat Trailer models.

Materials Include:

2 – 3/8″-16 x 4.19″ x 3″ Galvanized U-Bolt

2 – 6" x 1.5" x 1.25" Galvanized Flat Plate

4 – 3/8″ Galvanized Tri-Lock Hex Nuts

MODEL: CFFNDRKITG-2213

Used on

General

2213/4B - Bunk Mounting Kit

These are all of the requisite materials needed to mount a 2" x 4" x 6' Black Marine Carpeted Bunk Board onto a 2213B trailer model. This kit can also be used to mount a 2" x 4" x 7' Black Marine Carpeted Bunk Board onto a 2214B trailer model.

Materials Include:

4 – 5/16" x 1-1/2″ Galvanized Hex Head Lag Screw

MODEL: CFBNKKIT-2213B

Used on

General

2213/4B - Fender Mounting Kit

These are all of the requisite materials needed to mount a Black Powder Coated Fender 13″ Tire onto the PWT2213B, and PWT2214B trailer models.

Materials Include:

4 – 3/8″ Zinc Hex Flange Top Lock Nut

MODEL: CFFNDRKIT-2213B

Used on

General

2212G - Fender Mounting Kit

These are all of the requisite materials needed to mount a Galvanized Fender 4.80 x 12” Tire onto a 2212G trailer model.

Materials Include:

4 – 3/8" Galvanized Tri-Lock Nut

MODEL: CFFNDRKIT-2212G

Used on

PWT-2212G

General

2212B - Bunk Mounting Kit

These are all of the requisite materials needed to mount a 2″ x 4″ x 5′ Black Marine Carpeted Bunk Board onto a 2212B trailer model.

Materials Include:

4 – 5/16" x 1-1/2″ Galvanized Hex Head Lag Screw

MODEL: CFBNKKIT-2212B

Used on

PWT-2212B

General

2212B - Fender Mounting Kit

These are all of the requisite materials to mount a Black Powder Coated Fender 4.80 x 12" Tire onto a 2212B trailer model.

Materials Include:

4 – 3/8″ Zinc Hex Flange Top Lock Nut

MODEL: CFFNDRKIT-2212B

Used on

PWT-2212B

General

Pontoon Boat Trailer Tandem Axle Fender Mounting Kit

This kit contains all of the requisite materials needed to mount a Tandem Axle Galvanized Pontoon Boat Trailer Fender onto all Tandem Axle Pontoon Boat Trailer models.

Materials Include:

4 – 3/8″-16 x 4.19″ x 3″ Galvanized U-Bolt

4 – 6" x 1.5" x 1.25" Galvanized Flat Plate

8 – 3/8″ Galvanized Tri-Lock Hex Nuts

MODEL: CFFNDRKIT-PTG(TA)

Used on

General

Jon Boat Trailer Bunk Mounting Kit

This kit contains all of the requisite materials needed to mount a 2″ x 4″ x 6′ Black Marine Carpeted Bunk Board onto every Jon Boat Trailer model.

Materials Include:

2 – 3/8″-16 x 3.06" x 2.38″ Galvanized U-Bolt

2 – 8″ Adjustable Bolster Bunk Bracket

2 – 3/8″-16 x 1" Galvanized Hex Head Bolt

2 – Galvanized Angular Swivel Bracket

6 – 3/8″-16 Galvanized Tri-Lock Nut

6 – 3/8″-16 Galvanized Flat Washer

4 – 5/16" x 1-1/2″ Galvanized Hex Head Lag Screw

MODEL: CFBNKKIT-JBT

Used on

General

'River Hawk' Jon Boat Trailer Bunk Mounting Kit

This kit contains all of the requisite materials needed to mount a 2″ x 4″ x 10′ Black Marine Carpeted Bunk Board onto the JBT-1600 'River Hawk' Style Jon Boat Trailer model.

Materials Include:

3 – 3/8″-16 x 3.06" x 2.38″ Galvanized U-Bolt

3 – 8″ Adjustable Bolster Bunk Bracket

3 – 3/8″-16 x 1" Galvanized Hex Head Bolt

3 – Galvanized Angular Swivel Bracket

6 – 3/8″-16 Galvanized Tri-Lock Nut

9 – 3/8″-16 Galvanized Flat Washer

6 – 5/16″ x 1-1/2″ Galvanized Hex Head Lag Screw

MODEL: CFBNKKIT-JBT(HAWK)

Used on

JBT-1600 'River Hawk'

General

Jon Boat Trailer Bow Support Bunk Mounting Kit

These are all of the requisite materials needed to mount a 2″ x 4″ x 2′ Black Marine Carpeted Bow Support Bunk onto all Jon Boat Trailer models.

Materials Include:

1 – 3/8″ x 3" x 4.5″ Galvanized U-Bolt

2 – 8″ Galvanized Adjustable Bolster Bunk Bracket

4 – 3/8″-16 x 1″ Galvanized Hex Head Bolts

2 – Galvanized Angular Swivel Bracket

4– 3/8″-16 Galvanized Tri-Lock Hex Nut

4 – 3/8″ Galvanized Flat Washer

4 – 5/16" x 1-1/2″ Galvanized Hex Head Lag Screw

1 - 5" x 1.25" x .25" Galvanized Flat Plate w/ 9/16" Holes

MODEL: CFBNKKIT-BOWSPRT

Used on

General

Galvanized Winch Assembly Mounting Kit

This kit contains all of the requisite materials needed to mount a Galvanized Winch Assembly onto all Galvanized PWT trailer models.

Materials Include:

2 – 3/8″ x 3.06" x 4.5″ Galvanized U-Bolt

2 – 5" x 1.25" x .25" Galvanized Flat Plate

4 – 3/8″ Galvanized USS Flat Washer

4 – 3/8″-16 Galvanized Tri-Lock Hex Nuts

MODEL: CFWNCHKITG

Used on

General

Zinc U Bolt Winch Assembly Mounting Kit for Black Powder Coated Trailers

This kit has all of the requisite materials needed to mount a Black Powder Coated Winch Assembly onto any Black Powder Coated PWT trailer model.

Materials Include:

2 – 3/8″-16 x 3" x 4.5″ Zinc U-Bolt

2 – 5" x 1.25" x .25" Zinc Flat Plate

4 – 3/8″-16 Zinc Plated Serrated Flange Nuts

MODEL: CFWNCHKIT-(PWC-Z)

Used on

General

Jon Boat Trailer Winch Assembly Mounting Kit

This kit contains all of the requisite materials needed to mount a 32" Galvanized Winch Assembly w/DL 600 onto all Jon Boat Trailer models.

Materials Include:

2 – 3/8″ x 3.06" x 5.25″ Zinc U-Bolt

2 – 5" x 1.25" x .25" Galvanized Flat Plate

4 – 3/8″-16 Serrated Zinc Flange Nuts

MODEL: CFWNCHKIT-(JBT)

Used on

General

Winch Poly Bow Roller Assembly

This kit is part of every Winch Assembly used on every PWT, and Jon Boat Trailer model.

Materials Include:

1 – Galvanized Bow Stop Bracket

1 – 3/8″-16 x 3.75″ Zinc Hex Head Cap Bolt

1 – 3/8″-16 Zinc Hex Flange Top Lock Nut

1 – 1/2″-13 x 4.5″ Zinc Hex Head Cap Bolt

1 – 1/2″-13 Zinc Top Lock Nut

1 – 3″ Amber Poly Bow Roller

2 – 3″ Amber Poly Bow Roller Bell End

2 – 1/2″- Zinc Flat Washer

MODEL: CFASSM-WNCHRLR(3)

Used on

General

3" Poly Bow Roller Assembly

This is a section of the Winch Poly Bow Roller Assembly.

Materials Include:

1 – 3″ Poly Bow Roller
2 – 3″ Poly Bow Roller Bell End
1 – 1/2″-13 x 4.5″ Zinc Bolt
2 – 1/2″ Zinc Flat Washer
1 – 1/2″-13 Top Lock Nut

MODEL: CFASSM-POLYRLR(3)

Used on

General

5″ Poly Keel Roller Assembly for 3" Wide Trailer

Materials Included:

1 – 5″ Amber Poly Keel Roller

2 – 12.5″ Galvanized Adjustable Keel Roller Bracket

1 – 1/2″-16 x 6″ Zinc Hex Head Cap Bolt

2 – 3/8″-16 x 3.75″ Zinc Hex Head Cap Bolt

2 – 1/2″ USS Zinc Plated Washer

1 – 1/2″ Zinc Top Lock Nut

2 – 3/8″ Zinc Hex Flange Top Lock Nut

MODEL: CFKEELRLRASSM

Used on

General

Coupler Mounting Kit for 3" Wide Trailer Tongues

This item is used to mount Couplers to all trailer models without Brakes.

Materials Include:

2 - 1/2″-13 x 4″ Zinc Hex Head Cap Bolt

2 - 1/2″- 13 Zinc Top Lock Nut

MODEL: CFCPLR-MNTKIT(NONBRK)

Used on

ALL COM-FAB TRAILER MODELS

General

Actuator Coupler Mounting Kit for 3" Wide Trailer Tongue

It is used to mount Actuators to all Pontoon Boat Trailer models w/ Brakes.

Materials Include:

3 - 1/2″-13 x 4″ Zinc Hex Head Cap Bolt

3 - 1/2″-13 Top Lock Nut Zinc

MODEL: CFCPLRNUT/BLT-KIT-3

Used on

General

Side Crank Swivel Jack Mounting Kit

This kit contains all of the  parts needed to mount the 1200 lb Side Crank Swivel Jack, as well as the 1500 lb Side Crank Swivel Jack to all trailer frame models

MODEL: CFJACK-MNTKIT

Used on

ALL COM-FAB TRAILER MODELS

General

Galvanized Axle Mounting Kit

This kit is used to mount Complete Galvanized Axles to all PWT, and Jon Boat Trailer models.

Materials Include:

2 - 1/2" x 3" Galvanized Hex Head Bolt

2 - 1/2"-13 Galvanized Tri-Lock Nuts

MODEL: CFAXLEMNTKITG

Used on

General

Black Powder Coated Axle Mounting Kit

This kit is used to mount Black Powder Coated Axles to Black Powder Coated PWT Trailer models.

Materials Include:

2 - 1/2" x 3" Zinc Hex Head Bolt

2 - 1/2"-13 Zinc Flange Top Lock Nut

MODEL: CFAXLEKIT-MOUNT(Z)

Used on
