PT-1400 MiniToon Parts

General

35' 4-Pin Wire Harness Assembled w/ Protective Sleeve

The wiring is pulled through the trailer frame to provide connection between the lighting and the vehicle. It connects to the vehicle with a 4-Pin Male Connector. This item comes with a 3/8 20" Protective Sleeve and 30" Ground with 1/2" Ring Terminal.

MODEL: CFWH35

Used on

General

3/8″-16 x 2.06″ x 5.25″ Zinc U-Bolt

This item is used with a 4" x 1" x .25" Galvanized Flat Plates w/ 1/2" Holes, and a 3/8"-16 Serrated Zinc Flange Nuts to mount Pontoon Boat Trailer Bunk Brackets onto all Pontoon Boat Trailer models.

See: Tall Galvanized Pontoon Boat Trailer Bunk Bracket Kit

MODEL: CFUBLT3/8X2.06X5.25Z

Used on

General

1/4″-20 Thread External Tooth Locknut, Zinc Nut for Tail Lights

- Two of these are used with 1/4″- 20 Tail Light Bolts to mount TecNiq 8 Function 6" LED Tail Lights to all current Com-Fab Trailer models.

- Two of these are used with 1/4″- 20 Tail Light Bolts to mount Dry Launch SP7 Red Tail Lights to all Pre-2018 Com-Fab trailer models.

- One of these is used w/ 2-3/4"-20 Thread Bolts to secure PWT winch strap to crank winch.

MODEL: CFNUT1/4LOCKZ

Used on

ALL COM-FAB TRAILER MODELS

General

3/8″-16 Serrated Zinc Flange Nut

This item is part of these kits:

- 3/8"-16 Zinc Hex Head Bolts to mount all Crank Winch Models onto all Winch Post models.

- Black Powder Coated Winch Assembly Mounting Kit

- Jon Boat Trailer Winch Assembly Mounting Kit

MODEL: CFNUT3/8SERTDZ

Used on

ALL Powder Coat Finish Trailer Models, and Most Galvanized Trailer Models for Winches

General

3/8″-16 x 1″ Zinc Hex Head Cap Bolt

This item is used with 3/8"-16 Serrated Zinc Flange Nuts to mount all crank winch models onto every type of winch post. It is also part of the 2213B - Bunk Mounting Kit used to mount bunks onto PWT-2213B, and PWT-2214B trailer models.

MODEL: CFBLT3/8X1Z

Used on

ALL COM-FAB TRAILER MODELS

General

Galvanized Side Mount Spare Tire Carrier

• This item is optional for all of our Galvanized Trailer models.
• It can accommodate wheels from 10" to 16.5" with a spare tire.
• It fits all 4 and 5 lug wheels with 4" and 4.5" diameter hole patterns.
• The galvanized finish provides long lasting protection.
• The item can mount to trailer frames up to 3" wide and 4" high.

*Used on Galvanized Trailer Models Only

TIEDOWN MODEL: #86098

MODEL: CFSTB-SIDE(G)

Installation Instructions

1. Using the spare tire carrier and spare tire as a guide, determine a suitable mounting location on trailer frame.

2. Slide U-bolt around the frame and through the holes in tire carrier.

3. Mount with flat washers, lock washers and nuts provided.

4. Using the spare tire to determine the correct holes to use, place the carriage bolts provided for mounting the spare tire in the holes of the rectangular plate. Bolt heads should be on the back side of the tire carrier. Secure bolts with “star” washers.

5. The mounting plate will accommodate several sizes of frames by using the various hole patterns.

6. Check position of the tire mount for proper clearance with the spare tire before tightening bolts.

7. Mount spare tire with 1/2" bolt, washers and hex nuts provided.

Optional for

ALL GALVANIZED TRAILER MODELS

General

3/16" S-Hook with Latch Trailer Safety Chain - 48"

48" 2000 LB safety chain with 3/16 in S-Hooks and latch

MODEL: CFSFTYCHN

Used On

• Comes with a 1/4" Nut.
• Brilliant illumination in a compact size
• IP 68 Rated - Dust and water proof
• TecSeal Urethane Potting - Guaranteed Circuit Board Protection
• Stud-mounted, no visible fasteners
• Reliable performance over 100,000 hours
• Vertical mount positions meets P2 specifications, while horizontal mount meets PC specifications

TecNiq Part No. S14-RRS1-1

MODEL: CFLIGHTSDMRKR-LED(TEC-R24)

Used on

General

Red Low Profile ID Light Bar w/ Ground Terminal

• Used on all Pontoon Trailer models
• Screws included with purchase
• Meets all FMVSS 108 requirements for wide and narrow vehicles
• IP68 Rated - Dust and water proof with hermetic seal
• TecSeal Urethane Potting - Guaranteed Circuit Board Protection
• Durable impact resistant lens
• Excellent UV Resistance - Automotive exterior lighting grade polycarbonate
• Reliable performance over 100,000 hours
• Can be mounted horizontal, vertical, or at any angle

TecNiq Model No. T10-RR00-1

MODEL: CFLIGHTBAR-LED(S-TEC)

Used On

General

Black Powder Coated Side Mount Spare Tire Carrier

• This item is optional for all of our Black Powder Coated Trailer models.
• It can accommodate wheels from 10" to 16.5" with a spare tire.
• It fits all 4 and 5 lug wheels with 4" and 4.5" diameter hole patterns.
• The powder coated finish provides long lasting protection.
• The item can mount to trailer frames up to 3" wide and 4" high.


*Used on Black Powder Coated Trailer Models Only

TIEDOWN MODEL: #86100

MODEL: CFSTB-SIDE(B)

Installation Instructions

1. Using the spare tire carrier and spare tire as a guide, determine a suitable mounting location on trailer frame.

2. Slide U-bolt around the frame and through the holes in tire carrier.

3. Mount with flat washers, lock washers and nuts provided.

4. Using the spare tire to determine the correct holes to use, place the carriage bolts provided for mounting the spare tire in the holes of the rectangular plate. Bolt heads should be on the back side of the tire carrier. Secure bolts with “star” washers.

5. The mounting plate will accommodate several sizes of frames by using the various hole patterns.

6. Check position of the tire mount for proper clearance with the spare tire before tightening bolts.

7. Mount spare tire with 1/2" bolt, washers and hex nuts provided.

Optional for

ALL BLACK POWDER COATED TRAILER MODELS

General

RAM 1200LB Side Crank Swivel Jack

This item fits 3″ x 5“ tongues. It comes with a 1200 lb Side Crank Swivel Jack Mounting Kit.

MAXIMUM CAPACITY: 1200LB

PACIFIC TRAILER PRODUCTS/RAM MODEL: MJ-1200B

MODEL: CFJACKSIDE-1200(RAM)

Used on

PWT-2214G
JBT-1200 (Formerly JBT-900)
JBT-1400
JBT-1600
JBT-1600 (EXT) ((Formerly JBT-1600 ‘RIVER HAWK’)
PT-1400 'MiniToon'
PT-/TT-1618
PT-/TT-1820
PT-/TT-2022

General

Weld Aid B-100 Brite Zinc Aerosol Spray Can

This product is used to touch up, and prevent rust and corrosion on all of our galvanized items for sale. The spray is 69% Zinc Metal ensuring that it matches the shine of any and all Hot-Dipped Galvanized Steel. It has a special no clog nozzle, and can cover up to 40 sq feet of steel. This item meets ASTM-A780 requirements for corrosion protection.

Read the Safety Instructions carefully before use of this item.

https://weldaid.com/wp-content/uploads/2018/11/1008302E.pdf

Specifications

Part No: B-100

UPC: 731592100013

Volume: 12.5 oz Primer

Used On

General

ST175/80R13 D Load Range 13″ Aluminum Tire & Wheel 65 psi

This item is an upgradable option for all Trailer Models with 13" Tires. Speed rating is 81 mph.

MODEL: CFTST175RLRD-VSPOKE

Upgrade for
